TF-260C7 FRESNEL INFINITY THEATERSPOT 260W LED 7 COLOURS
Price on request
TF-260C7 FRESNEL INFINITY THEATERSPOT 260W LED 7 COLOURS
The new standard in theatre lighting, the Infinity Signature series. The tool you have always wanted to use to create beautiful, energy-efficient lighting for your theatre, church, studio or school. The...
All product information
Approx. 3-7 business days
S2 Ref: 200203
Delivery
Approx. 3-7 business days
S2Store Genk (BE)
Approx. 3-7 business days
Pros and Cons
Description
TF-260C7 FRESNEL INFINITY THEATERSPOT 260W LED 7 COLOURS
TF-260C7 FRESNEL INFINITY THEATERSPOT 260W LED 7 COLOURS
The new standard in theatre lighting, the Infinity Signature series. The tool you have always wanted to use to create beautiful, energy-efficient lighting for your theatre, church, studio or school. These fixtures use the latest LED technology with European software, whose operation and lens options are familiar to every entertainment technician. In Robert Juliat we found an excellent partner for creating this new series of theatre lighting.
The Infinity Signature TS-260C7 fixture is extremely well suited for theatre and film. Effortlessly selecting the right colour temperature, adding the perfectly calibrated colour from the virtual colour picker, eliminating the rolling-shutter effect and built-in tungsten simulations: all these features together make the TS-260C7 the fixture for every TV application. For the TS-260C7 Fresnel, illuminating larger areas in a specific colour is no problem. With the intelligent RGB, CMY or HSI colour control, the desired colour is always within reach without having to worry about the best mix of the 7-colour source. The zoom mechanism operates simply and intuitively, both manually and motorised via DMX from 15° to 50°
The Infinity Signature TS-260C7 fixture is extremely well suited for theatre and film. Effortlessly selecting the right colour temperature, adding the perfectly calibrated colour from the virtual colour picker, eliminating the rolling-shutter effect and built-in tungsten simulations: all these features together make the TS-260C7 the fixture for every TV application. For the TS-260C7 Fresnel, illuminating larger areas in a specific colour is no problem. With the intelligent RGB, CMY or HSI colour control, the desired colour is always within reach without having to worry about the best mix of the 7-colour source. The zoom mechanism operates simply and intuitively, both manually and motorised via DMX from 15° to 50°
Features:
-
The output of a 1 kW tungsten halogen unit
-
Lumiled 260 W 7-colour LED engine with custom array
-
Consistent CRI >96 across the full CCT range
-
Linear LED colour compensation
-
Colour temperature shift compensation (on all LEDs)
-
Colour shift compensation
-
Manual and motorised zoom (15°–50°)
-
Colour wheel with 64 matching filter gels
-
2000 – 8000K seamless CCT channel
-
RGB, CMY and HSI colour control
-
16-bit intelligent virtual dimming with high resolution
-
Tungsten mode with natural simulation of colour shift and timing
-
Flicker-free with selectable PWM via DMX
-
Custom-built silent cooling system
-
DMX mode (1 channel) for conventional replacement
Brief specifications
| Lichtbron | |
|---|---|
| Type lichtbron | led |
| Vermogen lichtbron | 260 W |
| Led-kleuren | RGBCALDB |
| Levensduur | 30000 u |
| CRI | 96 |
| CCT minimaal | 2000 K |
| CCT maximaal | 8000 K |
| Optisch | |
|---|---|
| Zoombereik | 15° - 50° |
| Zoomtype | handmatig, gemotoriseerd |
| Aansturing en Programmering | |
|---|---|
| Aansturing | DMX, handmatig |
| DMX-kanalen | 1, 6, 7, 11, 21 |
| Protocollen | DMX, RDM |
| Dimcurve | Lineair, Vierkant, S-Curve |
| Dimmerresolutie | 16 bit |
| Zoomresolutie | 8 bit |
| CMY- & CTO-resolutie | 8 bit |
| Dimmer | 0-100 % |
| Strobe | 0-20 Hz |
| Kleurensysteem | kleurenwiel CMY & CTO |
| Elektrische Specificaties en Aansluitingen | |
|---|---|
| Ingangsspanning | 100-240 V AC 50/60 Hz |
| Vermogensverbruik | 280 W |
| Power-connectoren | powerCON blauw, powerCON grijs |
| DMX-connectoren | XLR 3p & XLR 5p in & out |
| Mechanische Specificaties | |
|---|---|
| Afmetingen | 474 x 322 x 457 mm |
| Gewicht | 8.3 kg |
| IP-waarde | IP20 (alleen binnengebruik) |
| Behuizing | aluminium |
| Kleur | zwart |
| Bedrijfstemperatuur | tot 40 °C |
| Inbegrepen Items | |
|---|---|
| Meegeleverde kabel | powerCON-kabel |
| Meegeleverde accessoires | filterframe |
