AXIS 880 AUDIENT MICROPHONE PREAMPLIFIER

ASP880 is an 8-channel microphone preamplifier & ADC that will transform your sessions into world-class recordings, the perfect complement to your setup. ASP880 offers eight of Audient's renowned console microphone pres, pristine converter technology and a versatile feature set that includes Variable Impedance and Variable High Pass Filters. All in one 1RU rack!

Features

• 8 x Class-A Preamplifiers for the microphone console
• High Performance Burr Brown AD Converters
• Variable Input Impedance
• Variable HPF
• 2 x Discrete JFET instrument input
• 8 x Insert point (between the microphone preamplifiers and AD converters)
• Digital outputs - ADAT, AES & S/PDIF
• Full metal housing
• Over £500 of plugins and software with ARC

Specifications:

MICROPHONE PREAMPLIFIERS:

• MIC GAIN: -10 to +60dB (-10dB Pad)
• LINE GAIN: -16 to +44dB (-10dB Path)*
• PHANTOM POWER: 48v +/-4v @ 10mA/channel
• MIC EIN: <-127.5dBu
• CMRR: >80dB @ 100 to 10kHz
• MAXIMUM LEVEL: +22dBu (+32dBu with Path)
• INPUT IMPEDANCE: Mic LO: 220Ω Balanced
• Mic MED: 1k2Ω Balanced
• Mic HI: 2k8Ω Balanced
• Line (All Z): >6kΩ Balanced
• FREQUENCY SPONSE: +/-0.5dB 10Hz to 100kHz
• CROSSTALK: <-85dBu @ 1kHz & 10kHz
• THD+N @ 0dBu (1kHz): 0.003% (-90.5dBu)
• SNR: >90dB
• HPF: Shiftable from 25Hz to 250 Hz, 2nd order (12dB/Octave)

DISCRETE JFET D.I (Channels 1 & 2):

• D.I GAIN: -10 to +60 dB (-10dB Pad)
• MAXIMUM LEVEL: +16dBu (typical), +22dBu
• INPUT IMPEDANCE: 1MegΩ Unbalanced
• FREQUENCY SPONSE: +/-0.5dB 10Hz to 50kHz
• THD+N @ 0dBu (1kHz): <0.03% (-70dBu)
• SNR: 89dB

LINE OUTPUTS:

• MAXIMUM OUTPUT LEVEL: +27.5dBu
• OUTPUT IMPEDANCE: <100Ω Balanced

ADC LINE INPUTS (Insert Returns):

• MAXIMUM INPUTS: +18dBu
• DIGITAL REFERENCE LEVEL: 0dBFS = +18dBu
• INPUTIMPEDANCE: >10kΩ Balanced
• FREQUENCY SPONSE: +/-0.5dB 10Hz to Fs/2
• CROSSTALK: <-80dBu @ 1kHz & 10kHz
• THD+N @ -1dBFS (1kHz): <0.002% (-94dB)
• THD+N @ -6dBFS (1kHz): <0.002% (-94dB)
• DYNAMIC RANGE: 113dB unweighted - 115dB A-weighted
• PIEK LED LINE-UP: +16dBu (-2dBFS)
• SIGNAL LED LINEUP: Variable brightness from -30dBu to -10dBu (-28dBFS)

DIGITAL i/o:

• ADAT 8 CHANNELS SMUX: 44.1 - 96kHz
• AES | S/PDIF 8 CHANNELS: 44.1 - 96kHz
• CLOCK Internal or External
• WORLDCLOCK INPUT 75Ω BNC

POWER SUPPLY:

• High stability, low noise internal SMPS
• Fanless, silent operation
• Works anywhere in the world without reconfiguring
• LINE VOLTAGES: 90 to 264V (a.c.)
• INTERNAL RAILS: +/-18VDC, +48VDC & +5VDC
• Fuse: T1A (1Amp Time Delay)
• CONSUMPTION: Maximum 40 Watts
