Linear 5 MKII 115 XA HK Audio 15-inch Fullrange Speaker
Linear 5 MKII 115 XA HK Audio 15-inch Fullrange Speaker / monitor housing
The LINEAR 5 MK II XA models are compact, flexible, multi-functional mid/high units with impressive range and crystal-clear, assertive sound. The multifunctional enclosure shape with angled monitor edge allows them to be used as low-feedback stage monitors or as powerful mid/high sys...
Delivery
S2Store Genk (BE)
Pros and Cons
Description
Linear 5 MKII 115 XA HK Audio 15-inch Fullrange Speaker
Linear 5 MKII 115 XA HK Audio 15-inch Fullrange Speaker / monitor housing
The LINEAR 5 MK II XA models are compact, flexible, multi-functional mid/high units with impressive range and crystal-clear, assertive sound. The multifunctional enclosure shape with angled monitor edge allows them to be used as low-feedback stage monitors or as powerful mid/high system units in combination with the subwoofers. The rotatable horns ensure optimum dispersion even when used on their side - although rotating the horn on the 110 XA and 112 XA is not strictly necessary due to the narrow dispersion angles. Even on small and narrow stages, precise sound coverage is possible without problems
Brief specifications
| Housing | |
|---|---|
| Dimensions | 45 x 68.5 x 42 cm |
| Weight | 27.2 kg |
| Construction material | multiplex/MDF |
| Sound | |
|---|---|
| Crossover frequency | 1.6 kHz FIR Crossover (72 dB/oct.) |
| Frequency response | +/-3 dB 57 Hz – 12 kHz |
| Frequency range | -10 dB 54 Hz – 19 kHz |
| HF driver | 1", 1.7" voice coil |
| LF driver | 1 x 15", 3" voice coil |
| SPL | 130 dB half space (70 Hz – 12 kHz) @ 10 % THD |
| Beam angle | 70° x 50° CD horn, roteerbare hoorn |
| Power | |
|---|---|
| Max SPL sound pressure level | 138 dB half space @ 10 % THD |
| Peak power | 1200 W |
| RMS power | 600 W |
| Amplifier configuration | Bi-amp |
| Amplifier class | D |
| Power supply | |
|---|---|
| Voltage | 1 A / 100–240 V |
| Audio I/O | |
|---|---|
| Inputs | 1 x XLR combo balanced |
| Outputs | 1 x XLR balanced + 1 x XLR balanced DSP out |
| Digital I/O | |
|---|---|
| DSP resolution | 24-bit |
| Network | |
|---|---|
| Network interface | EtherCON RJ45, 1 x In |
