PowerZone™ 252 BLAZE Audio Amplifier
PowerZone 252 Amplifier BLAZE
The PowerZone 252 is a 2 x 125 Watt power amplifier in a semi-wide, 1U format. It drives both low impedance (4Ω to 16Ω) and constant voltage (70V/100V) loudspeaker loads. to drive Lo-Z or Hi-Z and, thanks to automatic power sharing, the total 250 watts can be proportionally distributed over the 2 output channels.
With a small form factor and o...
Delivery
S2Store Genk (BE)
Pros and Cons
Description
PowerZone™ 252 BLAZE Audio Amplifier
PowerZone 252 Amplifier BLAZE
The PowerZone 252 is a 2 x 125 Watt power amplifier in a semi-wide, 1U format. It drives both low impedance (4Ω to 16Ω) and constant voltage (70V/100V) loudspeaker loads. to drive Lo-Z or Hi-Z and, thanks to automatic power sharing, the total 250 watts can be proportionally distributed over the 2 output channels.
With a small form factor and only 1.9 kg, this is a powerful amplifier for its size and can be installed where others cannot.
Brief specifications
| Housing | |
|---|---|
| Dimensions | 44.5 x 220 x 262 mm |
| Weight | 1.9 kg |
| Sound | |
|---|---|
| Frequency response | 20 Hz - 20 kHz (+0/-0.25 dB (8 Ω load, 3 dB below rated power) |
| Signal-to-noise ratio | > 100 dB (A-weighted, 20 Hz - 20 kHz, 8 Ω load) |
| THD (total harmonic distortion) | < 0.05 % (20 Hz - 20 kHz, 8 Ω load, 3 dB below rated power) |
| Power | |
|---|---|
| Peak power | 2 x 125 W |
| Amplifier configuration | Totaal vermogen: 250 W |
| Amplifier class | UMAC™ Class D |
| Power supply | |
|---|---|
| Voltage | 100-240V, 50-60Hz |
| Power supply | UREC™ universal mains switch mode power supply with Power Factor Correction (PFC) |
| Consumption | 75W - 0.5W standby |
