Quantum ES 2 PreSonus USB-C Audio Interface
End of line - this product is leaving our range.
- High-quality signal flow – Custom low-latency drivers and low-noise converters.
- Brand-new MAX-HD microphone preamplifiers – As the crowning achievement of 30 years of innovation, our thoroughly redesigned preamps feature digitally controlled analog technology with a gain range of 75 dB.
- Developed in collaboration with Fender – Front-panel instrument input, specially designed for guitarists by leading experts.
- Includes professional recording software: Fender Studio Pro licence.
- Auto Gain – Effortlessly set record-ready levels.
- Universal Control app – Full control and metering from your mobile device, desktop or tablet.
2 x 2, 24-bit / 192 kHz recording interface including Fender Studio Pro licence for unlimited use
Capture your creativity with the Quantum ES 2 – the recording interface for musicians and audio creators.
The Quantum ES 2 is the result of 30 years of innovation and features two newly designed high-definition MAX-HD microphone preamplifiers with +75 dB of gain, making it ideally suited for today's most popular microphones. Guitarists and bassists will love the instrument input, developed in collaboration with Fender engineers. An Auto Gain button sets the perfect gain level for your microphones and instruments, while an illuminated push-encoder provides flexible control over gain level and output volume. And bright, responsive LED meters offer simple visual feedback for your inputs and outputs, making the unit perfectly suited for self-produced recordings.
Brief specifications
| Microfoon Inputs | |
|---|---|
| Connectietype | XLR Female (Combo), Balanced |
| Frequentierespons | 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz) |
| Input Impedantie | 1600 Ohm |
| Dynamisch Bereik | 113 dB (A-Weighted, Minimum Gain) |
| EIN | -129 dBu (Maximum Gain, 150 Ohms, 22 kHz BW, A-Weighted) |
| THD+N | 0.001% (1 kHz, Minimum Gain) |
| Gain Range | 75 dB |
| Maximum Input Level | +14 dBu (Balanced, Minimum Gain) |
| Phantom Power | +48 VDC |
| Line Inputs | |
|---|---|
| Frequentierespons | 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz) |
| Input Impedantie | 10K Ohm |
| Dynamisch Bereik | 114 dB (A-Weighted, Minimum Gain) |
| THD+N | 0.001% (1 kHz, Minimum Gain) |
| Gain Range | +/- 10 dB |
| Maximum Input Level | +15 dBu (Balanced, Minimum Gain) |
| Instrument Inputs | |
|---|---|
| Frequentierespons | 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz) |
| Dynamisch Bereik | 111 dB (A-Weighted, Minimum Gain) |
| THD+N | 0.002% (1 kHz, Minimum Gain) |
| Gain Range | 75 dB |
| Maximum Input Level | +15 dBu (Unbalanced, Minimum Gain) |
| Main Outputs | |
|---|---|
| Connection Type | 1/4" TRS Female |
| Headphone Outputs | |
|---|---|
| Connection Type | One - 1/4" TRS Female Stereo |
| Frequency Response | 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz) |
| Impedance Working Range | 22 Ohm |
| Dynamic Range | 111 dB (A-Weighted) |
| THD+N | 0.02% (1 kHz) |
| Maximum Output Level | 7.5 dBu (50 Ohms) |
| MIDI I/O | |
|---|---|
| Connection Type | 3.5 mm Type-B |
| Digital Audio | |
|---|---|
| Connector | USB-C |
| Bit Depth | 24-bit |
| Dynamic Range | 120 dB |
| Supported Sample Rates | 44.1, 48, 88.2, 96, 176.4, 192 (kHz) |
| Measurements | |
|---|---|
| Afmetingen | 483.3 x 158 x 175 mm |
| Gewicht | 680 g |
